Wireless Controller PJ-5 Touch Series
Wireless Controller PJ-5 Touch Series
Couldn't load pickup availability
The Wireless Controller PJ-5 Touch Series provides sleek, touch-sensitive control for compatible smart lighting systems without the need for additional control wiring. Featuring a modern glass-touch interface, the PJ-5 allows users to turn lights on or off, adjust brightness, and recall preset lighting scenes with a simple touch.
Powered by a 3V CR2032 lithium battery (included), the controller mounts easily to virtually any flat surface using the included adhesive backing, making it ideal for new construction, remodels, and retrofit lighting applications.
The PJ-5 communicates wirelessly using LeMesh Inside 2.4G Mesh technology and supports multiple smart lighting ecosystems, providing reliable wireless control up to 98 ft (30 m) in open areas.
Features
- Wireless touch wall controller
- Modern capacitive glass-touch interface
- On/Off lighting control
- Brightness adjustment
- Scene recall functionality
- Wireless installation — no control wiring required
- Surface mounts using included adhesive backing
- Powered by 1 × CR2032 3V lithium battery (included)
- LeMesh Inside 2.4G Mesh wireless communication
- Supports:
- LeMesh Inside
- SIG Mesh
- Tuya Zigbee
- Tuya Bluetooth
- Xiaomi Bluetooth
- Wireless range up to 98 ft (30 m) line of sight
- Ultra-low standby current: <5 μA
- Operating temperature: -4°F to 140°F (-20°C to 60°C)
- Slim, modern wall-mounted design
- Champagne Bronze finish
- Ideal for residential and commercial lighting control
Available Model
Champagne Bronze
| Color | Model No. |
|---|---|
| Champagne Bronze | PJ5-TOUCH-WH |
Specifications
| Specification | Details |
|---|---|
| Product Type | Wireless Touch Wall Controller |
| Series | PJ-5 Touch Series |
| Installation | Surface Mounted |
| Mounting Method | Adhesive Backing |
| Communication | LeMesh Inside 2.4G Mesh |
| Compatible Protocols | LeMesh Inside, SIG Mesh, Tuya Zigbee, Tuya Bluetooth, Xiaomi Bluetooth |
| Wireless Range | Up to 98 ft (30 m), Line of Sight |
| Power Source | 1 × CR2032 3V Lithium Battery |
| Battery Included | Yes |
| Standby Current | <5 μA |
| Operating Temperature | -4°F to 140°F (-20°C to 60°C) |
| Dimensions | 3" × 4" × 0" (86 × 90 × 11 mm) |
| Color | Champagne Bronze |
Applications
Perfect for:
- Smart Homes
- Residential Lighting
- Luxury Homes
- Hotels
- Restaurants
- Retail Stores
- Jewelry Showrooms
- Office Spaces
- Hospitality Lighting
- Architectural Lighting
- Wireless Retrofit Projects
- Smart LED Lighting Control
What's Included
- 1 × Wireless Controller PJ-5 Touch Series
- 1 × CR2032 3V Lithium Battery
- 1 × Adhesive Mounting Pad
- User Documentation
Compatible With
Designed for compatible lighting systems supporting:
- LeMesh Inside
- SIG Mesh
- Tuya Zigbee
- Tuya Bluetooth
- Xiaomi Bluetooth
Compatibility depends on the lighting system, receiver, gateway, and control configuration being used.
Why Choose the PJ-5 Touch Series?
The Wireless Controller PJ-5 Touch Series combines a refined glass-touch interface with intuitive wireless lighting control, providing an elegant way to manage compatible smart lighting systems without running additional control wiring.
With 2.4G Mesh wireless communication, ultra-low standby power consumption, adhesive surface mounting, and a slim Champagne Bronze design, the PJ-5 provides a flexible and sophisticated lighting control solution for modern residential, hospitality, retail, and commercial environments.
