Diamond Brite LEDs
5.5W/FT Plaster-In Linear Edge 3313 Series
5.5W/FT Plaster-In Linear Edge 3313 Series
Couldn't load pickup availability
The 5.5W/FT Plaster-In Linear Edge 3313 Series is a low-profile recessed LED lighting system designed for seamless integration into walls and ceilings. Consuming only 5.5 watts per foot, the series provides efficient architectural illumination with a clean plaster-in installation that minimizes visible fixture hardware.
Designed for flexible architectural applications, the Linear Edge 3313 Series can be cut every 2" (50 mm) for customized lengths and is available with multiple optical and color temperature configurations. Its 24V constant-voltage operation makes it suitable for continuous linear lighting, ceiling details, coves, accent lighting, and other integrated architectural installations.
Features
- Energy-efficient 5.5W per foot operation
- Low-profile recessed plaster-in design
- Creates a clean, integrated architectural appearance
- High-output LED light engine
- Cuttable every 2" (50 mm) for customized lengths
- Standard & custom lengths available
- Multiple optical configurations available
- Color temperatures from 2700K to 6500K
- High-CRI options up to CRI 95
- RGB+WWW option for dynamic color & white-light applications
- 24V constant-voltage operation
- IP20 rated
- UL Listed
Color Temperature Options
| Color Temperature | CRI |
|---|---|
| 2700K | 95 |
| 3000K | 95 |
| 4200K | 90 |
| 5000K | 88 |
| 6500K | 85 |
| RGB+WWW | Varies by Color Configuration |
Specifications
| Product Type | Plaster-In Recessed Linear LED |
|---|---|
| Series | Linear Edge 3313 Series |
| Power | 5.5W/FT |
| Input Voltage | 24V Constant Voltage |
| Mounting | Recessed Plaster-In |
| Cutting Increment | 2" (50 mm) |
| Length Options | Standard & Custom Lengths |
| Color Temperatures | 2700K / 3000K / 4200K / 5000K / 6500K / RGB+WWW |
| Maximum CRI | 95 |
| Optics | Multiple Options Available |
| IP Rating | IP20 |
| Listing | UL Listed |
Applications
- Architectural Lighting
- Ceiling Lighting
- Cove Lighting
- Wall-Integrated Lighting
- Accent Lighting
- Area Lighting
- Office & Commercial Interiors
- Retail Environments
- Hospitality Spaces
- Residential Interiors
Why Choose the Plaster-In Linear Edge 3313 Series?
The Plaster-In Linear Edge 3313 Series combines efficient 5.5W/FT operation with a recessed architectural design that integrates directly into walls and ceilings. Its ability to be cut every 2" (50 mm) provides flexibility for customized linear runs, while multiple optical and color temperature configurations allow the system to be tailored to a wide range of lighting designs.
With high-CRI white-light options, RGB+WWW capability, 24V constant-voltage operation, and UL listing, the Linear Edge 3313 Series provides a versatile solution for modern architectural, commercial, hospitality, retail, and residential lighting applications.
