Diamond Brite LEDs
Cable Suspended Nitrogen 3 Series
Cable Suspended Nitrogen 3 Series
Couldn't load pickup availability
The Cable Suspended Nitrogen 3 Series is a versatile architectural linear LED luminaire designed for modern commercial interiors requiring flexible light distribution and a refined suspended profile. Configurable for direct, indirect, or 360° rotational light distribution, the series provides precise illumination for offices, boardrooms, galleries, retail environments, and high-end architectural spaces.
Available in lengths from 2 ft to 8 ft, as well as continuous runs and custom welded patterns, the Cable Suspended Nitrogen 3 offers multiple outputs, optics, color temperatures, specialty lighting configurations, dimming protocols, and finishes for project-specific lighting designs.
Features
- Direct, indirect, or 360° rotational light distribution
- Power levels from 16W to 48W per 4 ft
- Light output from 1,944 to 5,236 lumens per 4 ft
- Efficacy from 109 to 121 lm/W
- Standard CCT options from 2700K to 5000K
- Dynamic White configuration from 2700K to 6500K
- Warm Dim configuration from 1800K to 2700K
- RGBW option available
- Available in 2 ft to 8 ft fixture lengths
- Continuous-run configurations available
- Custom welded patterns available
- Flood, Narrow Flood, Wall Wash, Graze, and Aisle optics
- 0–10V, DALI, DMX, and Lutron Ecosystem dimming options
- Satin Clear, White, Black, and Custom powder-coat finishes
- Cable-suspended architectural mounting
Standard Color Temperature Options
| Color Temperature | Option |
|---|---|
| 2700K | Available |
| 3000K | Available |
| 3500K | Available |
| 4000K | Available |
| 5000K | Available |
Specialty Lighting Options
| Option | Color Range |
|---|---|
| Dynamic White | 2700K–6500K |
| Warm Dim | 1800K–2700K |
| RGBW | RGB + White |
Optics Options
| Optic | Availability |
|---|---|
| Flood | Available |
| Narrow Flood | Available |
| Wall Wash | Available |
| Graze | Available |
| Aisle | Available |
Dimming & Control Options
| Protocol | Availability |
|---|---|
| 0–10V | Available |
| DALI | Available |
| DMX | Available |
| Lutron Ecosystem | Available |
Finish Options
| Finish | Availability |
|---|---|
| Satin Clear | Available |
| White | Available |
| Black | Available |
| Custom Powder Coat | Available |
Specifications
| Product Type | Cable-Suspended Architectural Linear LED Luminaire |
|---|---|
| Series | Cable Suspended Nitrogen 3 |
| Light Distribution | Direct / Indirect / 360° Rotational |
| Power Range | 16W–48W per 4 ft |
| Light Output | 1,944–5,236 lm per 4 ft |
| Efficacy | 109–121 lm/W |
| Standard CCT | 2700K / 3000K / 3500K / 4000K / 5000K |
| Dynamic White | 2700K–6500K |
| Warm Dim | 1800K–2700K |
| Color Lighting | RGBW Available |
| Available Sizes | 2 ft–8 ft |
| Custom Configurations | Continuous Runs / Custom Welded Patterns |
| Optics | Flood / Narrow Flood / Wall Wash / Graze / Aisle |
| Dimming & Controls | 0–10V / DALI / DMX / Lutron Ecosystem |
| Finish Options | Satin Clear / White / Black / Custom Powder Coat |
| Mounting | Cable Suspended |
Applications
- Boardrooms
- Corporate Offices
- Galleries
- Retail Environments
- Showrooms
- High-End Commercial Interiors
- Architectural Spaces
- Custom Linear Lighting Installations
Why Choose the Cable Suspended Nitrogen 3?
The Cable Suspended Nitrogen 3 provides exceptional design flexibility through direct, indirect, and 360° rotational light distribution. With outputs ranging from 1,944 to 5,236 lumens per 4 ft, multiple architectural optics, and efficacy up to 121 lm/W, the series can be configured for both general illumination and specialized accent applications.
Standard and specialty color options, advanced dimming protocols, multiple finishes, continuous runs, and custom welded patterns make the Cable Suspended Nitrogen 3 a highly customizable solution for boardrooms, galleries, retail environments, offices, and sophisticated commercial interiors.
