8W/FT Linear Las Vegas AS1 Series
8W/FT Linear Las Vegas AS1 Series
Couldn't load pickup availability
The 8W/FT Linear Las Vegas AS1 Series is a rigid LED bar system designed for architectural, accent, decorative, and general lighting applications. Featuring RGB + Warm White + Cool White (RGBWWW) LEDs, the series provides flexible color-changing illumination alongside dedicated warm and cool white light output.
Operating at 24V constant voltage and consuming only 8W per foot, the Linear Las Vegas RGBWWW AS1 Series is available in multiple standard and custom lengths. With 4.0" (100 mm) cut intervals, multiple optical covers, and IP ratings from IP20 through IP68, the system can be configured for a wide range of indoor and outdoor architectural lighting projects.
Features
- 8W per foot power consumption
- Rigid linear LED bar design
- RGB + Warm White + Cool White (RGBWWW) LED configuration
- Dynamic color-changing capabilities
- Dedicated warm and cool white illumination
- High-output light engine for strong, uniform illumination
- Cuttable every 4.0" (100 mm)
- Custom lengths available
- 24V constant-voltage operation
- Clear, Semi-Clear, and Frosted cover options
- IP20 through IP68 configurations available
- UL Listed for wet locations
- Suitable for architectural, commercial, indoor, and outdoor applications depending on selected IP configuration
Available Lengths & Power
| Length | Power |
|---|---|
| 6" (152 mm) | 4W |
| 24" (610 mm) | 16W |
| 48" (1,219 mm) | 32W |
| 78" (1,981 mm) | 52W |
| 86" (2,184 mm) | 57.3W |
| 120" (3,048 mm) | 80W |
Custom lengths are available based on project requirements and 4.0" (100 mm) cut intervals.
RGBWWW Lighting
| LED Channel | Function |
|---|---|
| Red | RGB Color Mixing |
| Green | RGB Color Mixing |
| Blue | RGB Color Mixing |
| Warm White | Dedicated Warm White Output |
| Cool White | Dedicated Cool White Output |
Optics Options
| Cover | Availability |
|---|---|
| Clear | Available |
| Semi-Clear | Available |
| Frosted | Available |
IP Rating Options
| IP Rating | Configuration |
|---|---|
| IP20 | Available |
| Up to IP68 | Available for Wet-Location Applications |
Specifications
| Product Type | Rigid RGBWWW Linear LED Bar |
|---|---|
| Series | Linear Las Vegas RGBWWW AS1 Series |
| LED Configuration | RGB + Warm White + Cool White (RGBWWW) |
| Power Consumption | 8W per Foot |
| Voltage | 24V Constant Voltage |
| Standard Lengths | 6" / 24" / 48" / 78" / 86" / 120" |
| Custom Lengths | Available |
| Cut Interval | 4.0" (100 mm) |
| Optics | Clear / Semi-Clear / Frosted |
| IP Rating Options | IP20–IP68 |
| Certification | UL Listed for Wet Locations |
Applications
- Architectural Lighting
- Ceiling Lighting
- Accent Lighting
- Decorative Lighting
- Area Lighting
- General Illumination
- Office Lighting
- Retail Environments
- Commercial Interiors
- Color-Changing Installations
- Indoor Lighting Projects
- Outdoor & Wet-Location Projects with Appropriate IP Configuration
Why Choose the Linear Las Vegas RGBWWW AS1 Series?
The Linear Las Vegas RGBWWW AS1 Series combines full RGB color mixing with dedicated Warm White and Cool White channels, providing extensive flexibility for both dynamic decorative effects and functional white illumination. Its rigid linear construction and 8W per foot power consumption make it suitable for a broad range of architectural and commercial lighting designs.
With 24V constant-voltage operation, custom lengths, 4.0" (100 mm) cut intervals, multiple optical covers, and configurations ranging from IP20 through IP68, the Linear Las Vegas RGBWWW AS1 Series provides a versatile solution for creative indoor, outdoor, accent, and wet-location lighting projects.
