Diamond Brite LEDs
7.62W/FT Flexible LED Xtreme Strip Series
7.62W/FT Flexible LED Xtreme Strip Series
Couldn't load pickup availability
The Flexible LED Xtreme Strip Series is a high-output, high-density flexible LED strip designed for architectural, decorative, display, and outdoor lighting applications. Featuring 240 LEDs per meter (73 LEDs per foot), the series delivers approximately 1,150 lumens per foot for powerful, smooth illumination in residential and commercial projects.
Consuming approximately 7.62W per foot (25W per meter), the Flexible LED Xtreme operates on 24V DC or 42V DC constant voltage and can be cut every 2" (50 mm) for custom installations. Multiple reel lengths, white CCTs, accent colors, dimming methods, and IP20 or IP66 configurations provide extensive flexibility for indoor and outdoor projects.
Features
- High-output flexible LED strip
- 240 LEDs per meter (73 LEDs per foot)
- Approximately 1,150 lumens per foot
- 25W per meter (7.62W per foot)
- Cuttable every 2" (50 mm)
- Multiple reel lengths up to 98.4 ft (30 m)
- 24V DC or 42V DC constant-voltage operation
- Wide 120° beam angle
- 3M VHB adhesive backing for secure installation
- White color temperatures from 2200K to 7500K
- Amber, Blue, Green, and Red accent color options
- DMX PWM, RF PWM, 0–10V, and MLV Incandescent dimming options
- IP20 configuration for indoor applications
- IP66 configuration for indoor/outdoor applications
- Approximately 50,000-hour rated life
White Color Temperature Options
| Color Temperature | Availability |
|---|---|
| 2200K | Available |
| 2700K | Available |
| 3000K | Available |
| 3700K | Available |
| 4200K | Available |
| 5000K | Available |
| 6500K | Available |
| 7500K | Available |
Accent Color Options
| Color | Wavelength |
|---|---|
| Amber | 580–590 nm |
| Blue | 465–475 nm |
| Green | 520–530 nm |
| Red | 620–630 nm |
Reel Length Options
| Reel Length | Total Power |
|---|---|
| 16.4 ft (5 m) | 125W |
| 26.2 ft (8 m) | 200W |
| 39.4 ft (12 m) | 300W |
| 98.4 ft (30 m) | 750W |
Dimming & Control Options
| Control Method | Availability |
|---|---|
| DMX PWM | Available |
| RF PWM | Available |
| 0–10V | Available |
| MLV Incandescent | Available |
IP Rating Options
| IP Rating | Application |
|---|---|
| IP20 | Indoor Applications |
| IP66 | Indoor / Outdoor Applications |
Specifications
| Product Type | High-Output Flexible LED Strip |
|---|---|
| Series | Flexible LED Xtreme Strip Series |
| LED Density | 240 LEDs/m (73 LEDs/ft) |
| Power Consumption | 25W/m (7.62W/ft) |
| Light Output | Approximately 1,150 lm/ft |
| Voltage | 24V DC / 42V DC Constant Voltage |
| Cut Interval | 2" (50 mm) |
| Beam Angle | 120° Wide Flood |
| Mounting | 3M VHB Adhesive Backing |
| Reel Lengths | 16.4 ft / 26.2 ft / 39.4 ft / 98.4 ft |
| White CCT Options | 2200K / 2700K / 3000K / 3700K / 4200K / 5000K / 6500K / 7500K |
| Accent Colors | Amber / Blue / Green / Red |
| Dimming & Control | DMX PWM / RF PWM / 0–10V / MLV Incandescent |
| IP Rating Options | IP20 / IP66 |
| Rated Life | 50,000 Hours |
Applications
- Cove Lighting
- Under-Cabinet Lighting
- Retail Lighting
- Display Showcases
- Architectural Accent Lighting
- Decorative Lighting
- Pathway Lighting
- Light Box Illumination
- Signage Backlighting
- Residential Lighting
- Commercial Lighting
- Outdoor Installations with IP66 Configuration
Why Choose the Flexible LED Xtreme Strip Series?
The Flexible LED Xtreme Strip Series combines 240 LEDs per meter with approximately 1,150 lumens per foot of high-output illumination, providing a powerful solution for architectural, decorative, display, and general accent lighting. Its 2" (50 mm) cut intervals allow the strip to be adapted to a wide variety of custom installation requirements.
With 24V DC and 42V DC options, multiple reel lengths, a wide 120° beam, multiple white and accent colors, several dimming methods, and IP20 or IP66 configurations, the Flexible LED Xtreme Strip Series provides a versatile solution for professional residential, commercial, architectural, and outdoor lighting projects.
