20W CHRONO Single-Head Modular Trimless Downlight Series
20W CHRONO Single-Head Modular Trimless Downlight Series
Couldn't load pickup availability
The 20W CHRONO Single-Head Modular Trimless Downlight Series delivers 2,050 lumens of powerful, precise illumination in a clean architectural format. Built around a CREE CXA1512 LED module with CRI 90, the CHRONO combines high light output with a trimless recessed design for seamless integration into modern residential and commercial ceilings.
Multiple beam angles, six color temperature options, and a choice of 120V TRIAC or 0–10V dimming provide flexibility for a wide range of lighting applications. Its modular construction features a replaceable LED module, while White, Black, and Mercury finish options allow the fixture to coordinate with different architectural environments.
Features
- 20W power consumption
- Produces 2,050 lumens per light module
- CREE CXA1512 LED light source
- CRI 90 for high-quality color rendering
- Available beam angles: 15° / 24° / 38° / 55°
- Available in 2700K / 3000K / 3500K / 4000K / 5000K / 5700K
- 120V TRIAC dimming option
- 0–10V dimming option
- Single-head configuration
- Modular trimless recessed design
- Replaceable LED module
- Available in White, Black, or Mercury finishes
- Recessed mounting frame ordered separately
- ETL Listed
Color Temperature Options
| Color Temperature | Description |
|---|---|
| 2700K | Warm White |
| 3000K | Warm White |
| 3500K | Neutral White |
| 4000K | Natural White |
| 5000K | Daylight |
| 5700K | Cool Daylight |
Beam Angle Options
| Beam Angle | Distribution |
|---|---|
| 15° | Narrow Beam |
| 24° | Medium-Narrow Beam |
| 38° | Medium Beam |
| 55° | Wide Beam |
Finish Options
- White
- Black
- Mercury
Specifications
| Product Type | Modular Trimless LED Downlight |
|---|---|
| Series | CHRONO |
| Configuration | Single Head |
| Power | 20W |
| Light Output | 2,050 lm |
| LED Source | CREE CXA1512 |
| CRI | 90 |
| Color Temperature | 2700K / 3000K / 3500K / 4000K / 5000K / 5700K |
| Beam Angles | 15° / 24° / 38° / 55° |
| Dimming Options | 120V TRIAC / 0–10V |
| Mounting | Trimless Recessed |
| Construction | Modular Design with Replaceable LED Module |
| Mounting Frame | Recessed Mounting Frame Ordered Separately |
| Finish Options | White / Black / Mercury |
| Certification | ETL Listed |
Applications
- Architectural Accent Lighting
- Retail Stores & Displays
- Galleries & Museums
- Showrooms
- Residential Interiors
- Commercial Interiors
- Hospitality Spaces
- Feature Lighting
Why Choose the CHRONO Modular Trimless Downlight?
The CHRONO Single-Head Modular Trimless Downlight Series combines 20W of power with 2,050 lumens of output and a high-quality CREE CXA1512 LED with CRI 90. Four available beam angles provide flexibility for focused accent lighting, display illumination, and broader architectural lighting applications.
With six color temperature options, 120V TRIAC or 0–10V dimming, a replaceable LED module, multiple finish options, and ETL listing, the CHRONO provides a flexible architectural lighting solution for retail, galleries, residential interiors, hospitality spaces, and commercial ceilings.
