Diamond Brite LEDs
8W BR20 Milano Lamp Series
8W BR20 Milano Lamp Series
Couldn't load pickup availability
The 8W BR20 Milano LED Lamp Series combines energy-efficient performance with reliable everyday illumination for residential and commercial interiors. Producing 500 lumens while consuming only 8 watts, the Milano provides an efficient replacement for traditional 50W incandescent, halogen, or CFL lamps.
Powered by BridgeLux LED technology, the Milano features a wide 110° beam angle for broad light distribution and smooth 10%–100% dimming for adjustable illumination. Its standard E26/E27 medium screw base makes it suitable for a variety of existing fixtures and recessed lighting applications.
Features
- 8W LED replaces up to 50W incandescent, halogen or CFL lighting
- Produces 500 lumens
- BridgeLux LED technology
- 110° wide beam angle for broad illumination
- Available in 3000K, 4000K, 5000K & 6500K
- Dimmable from 10%–100%
- Integrated isolated driver design
- CRI >80 for accurate color rendering
- Power factor >0.90
- Standard E26/E27 medium screw-in base
- 120V AC, 50/60Hz operation
- White PVC housing
- Approximately 25,000-hour rated life
- UL, CE, RoHS, FCC & Energy Star certified
- 3-year warranty
Color Temperature Options
| Color Temperature | Description | Light Output |
|---|---|---|
| 3000K | Warm White | 500 lm |
| 4000K | Soft White | 500 lm |
| 5000K | Pure White | 500 lm |
| 6500K | Bright White | 500 lm |
Specifications
| Product Type | BR20 LED Lamp |
|---|---|
| Series | Milano Series |
| Power | 8W |
| Equivalent Wattage | Up to 50W Incandescent / Halogen / CFL |
| Light Output | 500 lm |
| LED Source | BridgeLux LED |
| Input Voltage | 120V AC, 50/60Hz |
| Color Temperatures | 3000K / 4000K / 5000K / 6500K |
| CRI | >80 |
| Beam Angle | 110° |
| Dimming | 10%–100% |
| Power Factor | >0.90 |
| Base | E26 / E27 Medium Screw Base |
| Housing Material | PVC |
| Finish | White |
| Diameter | 2.5" (63 mm) |
| Height | 3.8" (96 mm) |
| Weight | 0.2 lb |
| Operating Temperature | -4°F to 122°F (-20°C to 50°C) |
| Rated Life | Approximately 25,000 Hours |
| Certifications | UL / CE / RoHS / FCC / Energy Star |
| Warranty | 3 Years |
Applications
- Recessed Can Lighting
- Pendant Lighting
- Ceiling Fixtures
- Wall Sconces
- Residential Interiors
- Offices
- Hospitality Spaces
- Commercial Indoor Lighting
Why Choose the Milano Series?
The 8W BR20 Milano LED Lamp delivers 500 lumens with a wide 110° beam angle, providing efficient and uniform illumination while replacing traditional lamps up to 50W. Four color temperature options make it easy to select the appropriate light appearance for different interior environments.
With BridgeLux LED technology, 10%–100% dimming, an E26/E27 medium screw base, high power factor, and an approximately 25,000-hour rated life, the Milano Series provides a versatile and energy-efficient lighting solution for residential, commercial, office, and hospitality applications.
