9W Micro Dot Recessed Trimless Downlight Series
9W Micro Dot Recessed Trimless Downlight Series
Couldn't load pickup availability
The 1" Micro Dot Recessed Trimless Downlight Series – 9W is a compact, high-performance architectural fixture designed for installations with limited plenum space. Its small 1" aperture, deep optical design, and multiple beam angle options provide precise illumination while maintaining a clean, minimalist ceiling appearance.
The 9W Micro Dot delivers up to 1,260 lumens and is available with multiple color temperatures, beam angles, dimming protocols, and Black or White finishes for residential, hospitality, retail, and commercial lighting applications.
Features
- Compact 1" (25 mm) aperture
- Designed for tight plenum applications
- 35° cut-off angle for improved glare control
- 9W power consumption
- Up to 1,260 lumens
- Universal 120V–277V AC input
- Multiple precision beam angles
- Multiple color temperature options
- 5CCT option available
- Remote external LED driver
- Dimmable
- Available in Black and White
- Powder-coated finish
- Supports 1/2"–1" (13–25 mm) ceiling thickness
- Wet location rated
- ETL Listed
- Title 24 compliant
- JA8 compliant
- 3-year product warranty
Available Model
| Power | 9W |
| Aperture | 1" (25 mm) |
| Model No. | RDMCRDOT-9W |
| Lumens | Up to 1,260 lm |
| Beam Angles | 17°, 24°, 40°, 50° |
Color Temperature & CRI Options
| Color Temperature | CRI |
| 2700K | 90 |
| 3000K | 90 |
| 3500K | 85 |
| 4000K | 85 |
| 5000K | 85 |
| 6500K | 85 |
| 5CCT – 2700K / 3000K / 4000K / 5000K / 6500K | — |
Beam Angle Options
- 17° – Narrow Spot
- 24° – Spot
- 40° – Medium Flood
- 50° – Wide Flood
Finish Options
- BLK – Black
- WHT – White
Specifications
| Product Type | Micro Dot Recessed Downlight |
| Installation | Recessed Trimless |
| Aperture | 1" (25 mm) |
| Cut-Off Angle | 35° |
| Power | 9W |
| Light Output | Up to 1,260 lm |
| Input Voltage | 120V–277V AC |
| Driver | Remote External Driver |
| Dimming | 0–10V or ELV / TRIAC |
| Dimming Range | 100%–5% |
| Beam Angles | 17°, 24°, 40°, 50° |
| Material | Aluminum |
| Trim Construction | Die-Cast Aluminum |
| Heat Sink | Aluminum |
| Finish | Powder-Coated Black or White |
| Ceiling Thickness | 1/2"–1" (13–25 mm) |
| Location Rating | Wet Location |
| Compliance | ETL Listed, Title 24, JA8 |
| Warranty | 3 Years |
Dimming Options
- 0–10V
- ELV / TRIAC
- Dimming range from 100% down to 5%
Applications
- Luxury Residential Interiors
- Retail Stores
- Jewelry Showrooms
- Hotels
- Restaurants
- Hospitality Spaces
- Offices
- Commercial Interiors
- Architectural Lighting
- Accent Lighting
- Display Lighting
- Tight Plenum Applications
What's Included
- 1 × 9W Micro Dot Recessed Downlight
- 1 × Remote External LED Driver
Additional controls, wiring, mounting accessories, and other components are sold separately unless otherwise specified.
Why Choose the 9W Micro Dot Recessed Downlight?
The 1" Micro Dot 9W Recessed Downlight delivers up to 1,260 lumens from an exceptionally compact aperture. Its 35° cut-off angle helps reduce glare, while four available beam angles provide flexibility for narrow accent lighting, display lighting, and wider illumination.
With multiple CCT options, universal 120V–277V operation, and compatibility with several dimming protocols, the 9W Micro Dot is an ideal solution for sophisticated residential and commercial lighting installations where ceiling space is limited.
