20W-32W Oracle Single Head Recessed Downlight Series
20W-32W Oracle Single Head Recessed Downlight Series
Couldn't load pickup availability
The 6" Oracle Single Head Recessed Downlight Series is designed for larger spaces requiring powerful, controlled illumination with a clean architectural appearance. Available in 20W and 32W configurations, the fixture delivers up to 3,945 lumens for demanding residential and commercial lighting applications.
With a choice of 15°, 30°, or 50° beam angles, color temperatures from 2700K to 5700K, and both Trimmed and Trimless configurations, the Oracle Single Head provides flexibility for focused accent lighting and broader illumination. White, Black, and Mercury finishes allow the fixture to integrate into a variety of modern interiors.
Features
- Architectural 6" recessed LED downlight
- 20W – 2,465 lumens
- 32W – 3,945 lumens
- Beam angle options: 15° / 30° / 50°
- Color temperature options from 2700K–5700K
- TRIAC 120V dimming
- Optional 0–10V dimming
- Available in Trimmed or Trimless configurations
- White, Black, or Mercury finish options
- ETL Listed
- IP40 Rated
Wattage & Light Output
| Wattage | Light Output | Efficacy |
|---|---|---|
| 20W | 2,465 Lumens | Approximately 123 lm/W |
| 32W | 3,945 Lumens | Approximately 123 lm/W |
Beam Angle Options
| Beam Angle | Lighting Distribution |
|---|---|
| 15° | Narrow Beam |
| 30° | Medium Beam |
| 50° | Wide Beam |
Design Options
| Option | Available Choices |
|---|---|
| Trim Style | Trimmed / Trimless |
| Finish | White / Black / Mercury |
| Color Temperature | 2700K–5700K |
| Beam Angle | 15° / 30° / 50° |
| Dimming | TRIAC 120V / Optional 0–10V |
Specifications
| Product Type | Single Head Recessed LED Downlight |
|---|---|
| Series | Oracle |
| Size | 6" (152 mm) |
| Head Configuration | Single Head |
| Wattage Options | 20W / 32W |
| Light Output | 2,465 / 3,945 Lumens |
| Beam Angles | 15° / 30° / 50° |
| Color Temperature | 2700K–5700K |
| Dimming | TRIAC 120V / Optional 0–10V |
| Trim Options | Trimmed / Trimless |
| Finishes | White / Black / Mercury |
| Certifications | ETL Listed |
| IP Rating | IP40 |
Applications
- Showrooms
- Offices
- Galleries
- High-Ceiling Residential Spaces
- Commercial Interiors
- Architectural Lighting
- Retail Environments
- Accent and General Lighting
Why Choose the 6" Oracle Single Head Recessed Downlight?
The 6" Oracle Single Head provides up to 3,945 lumens of powerful illumination while offering three beam angle options for precise control over light distribution. Its 20W and 32W configurations make it suitable for larger spaces where higher light levels and architectural flexibility are required.
With Trimmed and Trimless configurations, White, Black, and Mercury finishes, color temperatures from 2700K to 5700K, TRIAC dimming with optional 0–10V control, ETL listing, and an IP40 rating, the Oracle Single Head is a versatile solution for showrooms, offices, galleries, commercial interiors, and high-ceiling residential projects.
