12W Panelite Square Recessed Downlight Series
12W Panelite Square Recessed Downlight Series
Couldn't load pickup availability
The 12W 6" Panelite Square Recessed Downlight Series delivers 1,000 lumens of efficient illumination in a clean, modern square design. As the largest fixture in the series, it provides increased light output for larger residential rooms and commercial interiors while consuming only 12 watts.
Featuring 5 selectable color temperatures from 2700K to 5000K, the Panelite Downlight allows the lighting appearance to be adjusted for different spaces and applications. TRIAC dimming, IC-rated construction, and a wet-location rating provide additional flexibility for living rooms, lobbies, retail stores, offices, and hospitality environments.
Features
- 12W power consumption
- Produces 1,000 lumens
- 5CCT selectable: 2700K / 3000K / 3500K / 4000K / 5000K
- TRIAC dimmable
- CRI 80
- Modern square design with smooth trim
- Recessed architectural profile
- IC rated
- Wet-location rated
- ETL Listed
- Energy Star Certified
- Rated for approximately 50,000 hours
Selectable Color Temperature
| Color Temperature | Description |
|---|---|
| 2700K | Warm White |
| 3000K | Warm White |
| 3500K | Neutral White |
| 4000K | Natural White |
| 5000K | Daylight |
Specifications
| Product Type | Square Recessed LED Downlight |
|---|---|
| Series | Panelite Downlight |
| Power | 12W |
| Light Output | 1,000 lm |
| Color Temperature | 5CCT Selectable: 2700K / 3000K / 3500K / 4000K / 5000K |
| CRI | 80 |
| Dimming | TRIAC Dimmable |
| Mounting | Recessed |
| Trim Style | Square / Smooth |
| IC Rating | IC Rated |
| Location Rating | Wet Location |
| Rated Lifespan | Approximately 50,000 Hours |
| Certifications | ETL Listed / Energy Star Certified |
Applications
- Large Living Rooms
- Lobbies & Reception Areas
- Retail Stores
- Office Spaces
- Hotels & Hospitality Spaces
- Commercial Interiors
- Residential Interiors
- General Architectural Lighting
Why Choose the Panelite Downlight?
The 12W 6" SQ Smooth Recessed Panelite Downlight delivers 1,000 lumens from a modern square fixture designed for larger residential and commercial spaces. Its 5CCT selectable technology provides the flexibility to choose between 2700K, 3000K, 3500K, 4000K, and 5000K to complement different environments.
With TRIAC dimming, IC-rated construction, wet-location suitability, ETL listing, Energy Star certification, and an approximately 50,000-hour rated lifespan, the Panelite provides an efficient recessed lighting solution for large living rooms, lobbies, retail stores, offices, hospitality spaces, and other commercial interiors.
