Diamond Brite LEDs
5W Hybrid Horizontal PL Retrofit Lamp - GU24 Base
5W Hybrid Horizontal PL Retrofit Lamp - GU24 Base
Couldn't load pickup availability
The 5W Hybrid Horizontal PL Retrofit Lamp with GU24 Base is an energy-efficient LED replacement for traditional 13W CFL lamps. Designed for horizontal fixture applications, it features a convenient GU24 twist-lock base and hybrid operation for both ballast-compatible and ballast-bypass installations.
With five available color temperatures, 120–277V operation, and an optional 347V configuration, the 5W Hybrid Horizontal PL Retrofit Lamp provides a versatile retrofit solution for hospitality spaces, apartments, commercial interiors, and other compatible GU24 fixtures.
Features
- 5W LED replacement for 13W CFL lamps
- Approximately 62% lower power consumption compared with a 13W CFL
- Designed for horizontal fixture applications
- Hybrid plug-and-play and direct-wire operation
- Ballast-compatible installation option
- Ballast-bypass installation option
- GU24 Twist-Lock Base
- 2700K, 3000K, 3500K, 4100K, and 5000K color temperature options
- 120–277V operation
- Optional 347V configuration
- Approximately 50,000-hour rated life
- UL Listed
- RoHS Compliant
Color Temperature Options
| Color Temperature | Availability |
|---|---|
| 2700K | Available |
| 3000K | Available |
| 3500K | Available |
| 4100K | Available |
| 5000K | Available |
Installation Options
| Installation Method | Configuration |
|---|---|
| Plug-and-Play | Ballast Compatible |
| Direct-Wire | Ballast Bypass |
Specifications
| Product Type | Hybrid Horizontal PL Retrofit Lamp |
|---|---|
| Wattage | 5W |
| CFL Replacement | 13W CFL |
| Power Reduction | Approximately 62% |
| Base | GU24 Twist-Lock |
| Orientation | Horizontal |
| Color Temperature | 2700K / 3000K / 3500K / 4100K / 5000K |
| Voltage | 120–277V |
| Optional Voltage | 347V |
| Installation | Plug-and-Play / Direct-Wire |
| Rated Life | 50,000 Hours |
| Certifications | UL Listed / RoHS Compliant |
Applications
- Hospitality Spaces
- Apartments
- Multi-Unit Housing
- Commercial Spaces
- Residential Interiors
- Horizontal CFL Retrofit Applications
- GU24 Fixture Retrofits
Why Choose the 5W Hybrid Horizontal PL Retrofit Lamp with GU24 Base?
The 5W Hybrid Horizontal PL Retrofit Lamp provides an efficient replacement for traditional 13W CFL lamps, reducing power consumption by approximately 62%. Its GU24 twist-lock base provides a convenient connection for compatible fixtures, while hybrid operation supports both ballast-compatible and ballast-bypass installations.
With five available color temperatures, 120–277V operation, an optional 347V configuration, a 50,000-hour rated life, UL listing, and RoHS compliance, this retrofit lamp provides a versatile solution for hospitality, apartments, multi-unit housing, and commercial lighting applications.
