5W Hybrid Horizontal PL Retrofit Lamp - E26 Base
5W Hybrid Horizontal PL Retrofit Lamp - E26 Base
Couldn't load pickup availability
The 5W Hybrid Horizontal PL Retrofit Lamp with E26 Base is a compact LED replacement for traditional 13W CFL lamps. Designed for horizontal fixtures, it provides an efficient retrofit solution for residential, office, retail, hospitality, and other commercial lighting applications.
Its hybrid design supports both plug-and-play ballast-compatible operation and direct-wire ballast-bypass installation. With an E26 medium screw base, five available color temperatures, and 120–277V operation, the lamp provides flexibility for a wide range of retrofit projects.
Features
- 5W LED replacement for 13W CFL lamps
- Designed for horizontal fixture applications
- Hybrid plug-and-play and direct-wire operation
- Ballast-compatible installation option
- Ballast-bypass installation option
- E26 Medium Screw Base
- 2700K, 3000K, 3500K, 4100K, and 5000K color temperature options
- 120–277V operation
- Optional 347V configuration
- Approximately 50,000-hour rated life
- UL Listed
- RoHS Compliant
Color Temperature Options
| Color Temperature | Availability |
|---|---|
| 2700K | Available |
| 3000K | Available |
| 3500K | Available |
| 4100K | Available |
| 5000K | Available |
Installation Options
| Installation Method | Configuration |
|---|---|
| Plug-and-Play | Ballast Compatible |
| Direct-Wire | Ballast Bypass |
Specifications
| Product Type | Hybrid Horizontal PL Retrofit Lamp |
|---|---|
| Wattage | 5W |
| Replacement | 13W CFL |
| Base | E26 Medium Screw Base |
| Orientation | Horizontal |
| Color Temperature | 2700K / 3000K / 3500K / 4100K / 5000K |
| Voltage | 120–277V |
| Optional Voltage | 347V |
| Installation | Plug-and-Play / Direct-Wire |
| Rated Life | 50,000 Hours |
| Certifications | UL Listed / RoHS Compliant |
Applications
- Residential Lighting
- Offices
- Retail Spaces
- Hotels
- Hospitality Lighting
- Commercial Interiors
- Horizontal CFL Retrofit Applications
Why Choose the 5W Hybrid Horizontal PL Retrofit Lamp?
The 5W Hybrid Horizontal PL Retrofit Lamp provides an efficient replacement for 13W CFL lamps while offering the flexibility of both ballast-compatible and ballast-bypass installation. Its E26 medium screw base and horizontal configuration make it a practical solution for compatible existing fixtures.
With five available color temperatures, 120–277V operation, optional 347V configuration, a 50,000-hour rated life, UL listing, and RoHS compliance, this hybrid retrofit lamp provides a versatile solution for residential, office, retail, hotel, and commercial lighting applications.
