40W Panerai Linear Light Series
40W Panerai Linear Light Series
Couldn't load pickup availability
The 40W Panerai 4' Linear Light Series is an economical, high-performance washdown LED fixture designed for demanding commercial and industrial environments. Delivering 4,760 lumens at an efficacy of 119 lm/W, the fixture provides powerful illumination for canopies, loading docks, warehouses, tunnels, stairwells, and other hard-to-reach areas where frequent re-lamping can be difficult or costly.
Built with an impact-resistant polycarbonate housing, stainless steel door clips, silicone gaskets, and an IP65 rating, the Linear Panerai Series is engineered for reliable operation in harsh and wet environments. Quick-mount surface brackets and V-hook suspension hardware are included for flexible installation.
Features
- 40W power consumption
- Produces 4,760 lumens
- High efficacy of 119 lm/W
- Available in 3000K / 4000K / 5000K / 6000K
- CRI 82
- Diffuse and Clear polycarbonate lens options
- Diffuse lens provides reduced glare
- Impact-resistant polycarbonate housing
- Stainless steel door clips
- Silicone gaskets for additional protection
- IP65 dust- and water-resistant construction
- Quick-mount surface brackets included
- V-hook suspension hardware included
- 120–277V constant-current driver
- Optional 480V configuration available
- Rated for approximately 50,000 hours at L70
- Minimum starting temperature of -4°F (-20°C)
- UL Listed for wet locations
- DLC Listed
- RoHS compliant
- Mercury-free and UV-free
- Designed as an energy-efficient replacement for 32W 2-lamp T8 fixtures
Color Temperature Options
| Color Temperature | Description |
|---|---|
| 3000K | Warm White |
| 4000K | Neutral White |
| 5000K | Cool White |
| 6000K | Bright White |
Lens Options
| Lens | Characteristics |
|---|---|
| Diffuse Polycarbonate | Low-Glare Light Distribution |
| Clear Polycarbonate | Clear Lens Configuration |
Mounting Options
| Mounting Type | Hardware |
|---|---|
| Surface Mount | Quick-Mount Surface Brackets Included |
| Suspended Mount | V-Hook Suspension Hardware Included |
Specifications
| Product Type | Washdown Linear LED Fixture |
|---|---|
| Series | Linear Panerai 4-Foot Series |
| Fixture Length | 4 ft |
| Power Consumption | 40W |
| Light Output | 4,760 lm |
| Efficacy | 119 lm/W |
| Color Temperature | 3000K / 4000K / 5000K / 6000K |
| CRI | 82 |
| Lens Options | Diffuse / Clear Polycarbonate |
| Housing | Impact-Resistant Polycarbonate |
| Door Clips | Stainless Steel |
| Gaskets | Silicone |
| Input Voltage | 120–277V |
| Optional Voltage | 480V |
| Driver | Constant Current |
| IP Rating | IP65 |
| Rated Lifespan | 50,000 Hours (L70) |
| Life Rating Method | LM-80 / TM-21 |
| Minimum Start Temperature | -4°F (-20°C) |
| Certifications | UL Listed for Wet Locations / DLC Listed / RoHS Compliant |
| Environmental | Mercury-Free / UV-Free |
Applications
- Canopies
- Gas Stations
- Loading Docks
- Warehouses
- Tunnels
- Stairwells
- Washdown Areas
- Commercial Facilities
- Industrial Facilities
- Hard-to-Reach Lighting Installations
- Harsh & Wet Environments
Why Choose the Linear Panerai 4-Foot Series?
The Linear Panerai 4-Foot Series combines 40W power consumption with 4,760 lumens of output for an efficacy of 119 lm/W. Its rugged polycarbonate construction, stainless steel clips, silicone gaskets, and IP65 rating make it particularly well suited for demanding commercial and industrial environments.
With multiple CCT and lens options, 120–277V operation, optional 480V compatibility, included surface and suspension mounting hardware, a 50,000-hour L70 rating, and UL wet-location and DLC listings, the Linear Panerai Series provides a durable and energy-efficient alternative to traditional 32W 2-lamp T8 fixtures.
