Diamond Brite LEDs
3W Trimless Duval Step Light Series
3W Trimless Duval Step Light Series
Couldn't load pickup availability
The 3W Trimless Duval Step Light Series provides clean, recessed illumination for indoor and outdoor architectural wall applications. Designed with a seamless trimless aesthetic, the Duval Series integrates discreetly into concrete, brick masonry, and drywall while providing functional illumination for steps, pathways, corridors, and architectural features.
Featuring 5CCT selectable technology, durable die-cast aluminum construction, and an IP65 wet-location-rated design, the Duval Series provides reliable performance for both interior and exterior installations.
Features
- 3W LED power consumption
- 120V AC, 50/60Hz operation
- 5CCT selectable color temperature
- 2700K, 3000K, 3500K, 4100K & 5000K
- High-lumen LEDs binned to Energy Star standards
- Clean trimless recessed design
- Die-cast aluminum housing
- Available in White or Black
- Corrosion-resistant painted finish
- Weather-sealed lens
- IP65 rated
- ETL listed for wet locations
- Approved for concrete pour applications
- IC Rated – can be completely covered with insulation
- Non-dimming LED driver
- Power factor >0.90
- Thermally protected driver with overload and short-circuit protection
- Approximately 50,000-hour rated life at 70% lumen maintenance
- No UV or IR emissions
- Lead and mercury free
- RoHS compliant
- 5-year warranty on LED components
5CCT Color Temperature Selection
| Color Temperature | Description |
|---|---|
| 2700K | Warm White |
| 3000K | Soft White |
| 3500K | Natural White |
| 4100K | Cool White |
| 5000K | Bright White |
The integrated 5CCT selector allows the color temperature to be selected during installation, providing flexibility for residential, commercial, hospitality, and architectural environments.
Finish Options
- White
- Black
Specifications
| Product Type | Trimless Recessed LED Step Light |
|---|---|
| Series | Duval Step Light Series |
| Power | 3W |
| Input Voltage | 120V AC |
| Frequency | 50/60Hz |
| Color Temperature | 5CCT – 2700K / 3000K / 3500K / 4100K / 5000K |
| Dimming | Non-Dimmable |
| Power Factor | >0.90 |
| Housing Material | Die-Cast Aluminum |
| Finish Options | White / Black |
| Lens | Weather-Sealed |
| Installation | Recessed / Trimless |
| Compatible Wall Types | Concrete Pour / Brick Masonry / Drywall |
| IC Rating | IC Rated |
| IP Rating | IP65 |
| Location Rating | ETL Listed for Wet Locations |
| Concrete Pour | Approved |
| Rated Life | Approximately 50,000 Hours at 70% Lumen Maintenance |
| Compliance | ETL / RoHS |
| Warranty | 5 Years on LED Components |
Driver Protection
- Integrated non-dimming LED driver
- Power factor >0.90
- Thermal protection
- Overload protection
- Short-circuit protection
Applications
- Step & Stair Lighting
- Pathway Lighting
- Outdoor Wall Lighting
- Indoor Architectural Wall Lighting
- Corridors & Hallways
- Residential Interiors & Exteriors
- Hotels & Hospitality
- Commercial Buildings
- Concrete & Masonry Installations
- Architectural Accent Lighting
Why Choose the Trimless Duval Step Light Series?
The Duval Series combines a clean trimless architectural appearance with durable construction for both indoor and outdoor installations. Its compatibility with concrete pour, brick masonry, and drywall provides installation flexibility across a wide range of residential and commercial projects.
With 5CCT selectability, IP65 protection, wet-location certification, IC-rated construction, and an approximately 50,000-hour rated life, the Duval Series provides a durable and versatile solution for step, pathway, wall, and architectural accent lighting.
