Diamond Brite LEDs
15W Architectural Inter-changeable Downlight Series
15W Architectural Inter-changeable Downlight Series
Couldn't load pickup availability
The 15W 3-Inch Interchangeable LED Downlight Series is a premium architectural lighting system designed for maximum flexibility, performance, and customization. Featuring a compact canless design with interchangeable trims, reflectors, and lenses, this fixture provides a versatile solution for modern commercial, hospitality, retail, gallery, and high-end residential interiors.
Delivering up to 1,300 lumens with CRI 90, the fixture provides excellent color rendering and powerful illumination from only 15W. A 355° rotation and 30° tilt provide precise directional control for accent, display, and general lighting applications.
Features
- 15W power consumption
- Up to 1,300 lumens
- 3" round LED downlight module
- Canless, low-profile design
- 120–277V universal voltage
- CRI 90 for excellent color rendering
- 0–10V dimming
- 355° rotation
- 30° adjustable tilt
- Interchangeable trim, reflector, and lens system
- Round and square trim options
- Trimless configurations available
- Multiple finish options
- 22° and 60° lens options
- Compatible with multiple cutout configurations
- IP20 rated for indoor applications
- Approximately 50,000-hour rated life
Color Temperature & Lumen Options
| Color Temperature | Description | Lumens |
|---|---|---|
| 2700K | Warm White | 1,100 lm |
| 3000K | Soft White | 1,200 lm |
| 3500K | Natural White | 1,250 lm |
| 4000K | Cool White | 1,300 lm |
Trim & Finish Options
- Round Adjustable Trim
- Square Adjustable Trim
- Trimless Options
- White Finish
- Black Finish
- Gold Finish
- Gloss Finish Options
- Reflector Options
Lens Options
| Beam Angle | Recommended Use |
|---|---|
| 22° | Focused Accent & Display Lighting |
| 60° | Wide Flood & General Illumination |
Specifications
| Product Type | Interchangeable LED Downlight |
|---|---|
| Fixture Size | 3" |
| Shape | Round LED Module |
| Installation | Canless / Recessed |
| Power | 15W |
| Light Output | 1,100–1,300 lm |
| Input Voltage | 120–277V |
| CRI | 90 |
| Color Temperatures | 2700K, 3000K, 3500K, 4000K |
| Dimming | 0–10V |
| Rotation | 355° |
| Tilt | 30° |
| Lens Options | 22° / 60° |
| Trim Options | Round, Square & Trimless |
| IP Rating | IP20 – Indoor Use |
| Rated Life | Approximately 50,000 Hours |
| Estimated Annual Energy Cost | Approximately $1.80* |
*Estimated annual energy cost may vary depending on operating hours and local electricity rates.
Available Accessories
- Emergency Driver
- Wire Extenders
- New Construction Plates
- Interchangeable Trims
- Interchangeable Reflectors
- 22° & 60° Lenses
Applications
- Commercial Interiors
- High-End Residential Lighting
- Hotels & Hospitality
- Retail Stores
- Jewelry Showrooms
- Gallery Lighting
- Museum Lighting
- Display Lighting
- Accent Lighting
- Architectural Lighting
- Restaurants & Lounges
Why Choose the 3-Inch Interchangeable LED Downlight Series?
The 3-Inch Interchangeable LED Downlight Series combines powerful 15W performance with up to 1,300 lumens and CRI 90 color rendering. Its 355° rotation and 30° tilt provide exceptional aiming flexibility for architectural, accent, and display lighting applications.
With interchangeable round, square, and trimless configurations, multiple finishes, 22° and 60° lens options, and a range of installation accessories, this modular system can be customized to meet the aesthetic and performance requirements of sophisticated residential and commercial lighting projects.
