20W Diamond Luxe Recessed Light Series
20W Diamond Luxe Recessed Light Series
Couldn't load pickup availability
The 20W Diamond Luxe Recessed LED Light Series delivers exceptional brightness, premium color quality, and adjustable directional illumination in a high-performance recessed design. Producing up to 2,550 lumens while consuming only 20 watts, the Diamond Luxe provides an energy-efficient alternative to traditional 150W lighting.
Featuring a 120° tilt and pivot design, a focused 45° beam angle, and an exceptional CRI >95, the Diamond Luxe provides precise lighting control with true-to-life color rendering. It is especially well suited for high-end retail, galleries, showrooms, hospitality spaces, and architectural interiors where light quality and adjustability are essential.
Features
- 20W LED replaces up to 150W traditional lighting
- Produces up to 2,550 lumens
- 1 × Cree high-performance LED
- 120° tilt and pivot design for adjustable directional lighting
- 45° beam angle for focused illumination
- Available in 3000K, 4200K, 5000K & 7000K
- Exceptional CRI >95 for true-to-life color rendering
- Wide-range 85–240V AC operation
- Power factor >0.90
- Durable aluminum alloy construction
- Designed for efficient heat dissipation
- Approximately 50,000-hour rated life
- Non-dimmable standard configuration
- Optional dimmable version available
Color Temperature & Lumen Output
| Color Temperature | Description | Lumens |
|---|---|---|
| 3000K | Warm White | 2,350 lm |
| 4200K | Soft White | 2,450 lm |
| 5000K | Pure White | 2,550 lm |
| 7000K | Ultra Bright White | 2,550 lm |
Specifications
| Product Type | Adjustable Recessed LED Light |
|---|---|
| Series | Diamond Luxe Series |
| Power | 20W |
| Equivalent Wattage | Up to 150W Traditional Lighting |
| Light Output | 2,350–2,550 lm |
| Input Voltage | 85–240V AC |
| LED Source | 1 × Cree High-Performance LED |
| Color Temperatures | 3000K / 4200K / 5000K / 7000K |
| CRI | >95 |
| Beam Angle | 45° |
| Adjustability | 120° Tilt & Pivot |
| Power Factor | >0.90 |
| Dimming | Non-Dimmable Standard / Dimmable Version Available |
| Material | Aluminum Alloy |
| Cutout Diameter | 4.1" (105 mm) |
| Fixture Diameter | 4.7" (120 mm) |
| Fixture Height | 5.1" (130 mm) |
| Operating Temperature | -4°F to 122°F (-20°C to 50°C) |
| Rated Life | Approximately 50,000 Hours |
Applications
- Jewelry Stores & Showcases
- High-End Retail
- Showrooms
- Art Galleries
- Museums & Exhibitions
- Merchandise Displays
- Hotels & Hospitality
- Restaurants
- Residential Interiors
- Commercial Interiors
- Architectural Accent Lighting
- Display & Feature Lighting
Why Choose the Diamond Luxe Series?
The Diamond Luxe Series combines up to 2,550 lumens with exceptional CRI >95 color rendering, making it an excellent choice for environments where accurate color presentation is critical. Its focused 45° beam provides controlled illumination for merchandise, artwork, architectural features, and other focal points.
With a 120° adjustable tilt and pivot design, Cree LED technology, four color temperature options, durable aluminum alloy construction, and an approximately 50,000-hour rated life, the Diamond Luxe Series provides a powerful and versatile solution for premium directional recessed lighting.
