Diamond Brite LEDs
20W E40 Clima Corn Lamp Series
20W E40 Clima Corn Lamp Series
Couldn't load pickup availability
The 20W Clima Corn Lamp Series – E40 Mogul Base combines energy-efficient performance and broad illumination in a compact LED lamp design. Producing up to 1,500 lumens while consuming only 20 watts, the Clima provides an efficient replacement for traditional lamps up to 100W.
Featuring Epistar LED technology, 48 high-power LEDs, and full 360° light distribution, the Clima provides broad, all-around illumination. Its E40 mogul screw-in base, wide-range voltage compatibility, durable aluminum and PVC construction, and rated life exceeding 50,000 hours make it a versatile solution for residential and commercial lighting applications.
Features
- 20W LED power consumption
- Equivalent to up to 100W traditional lighting
- Produces up to 1,500 lumens
- E40 mogul screw-in base
- 48 high-power LEDs
- Epistar LED technology
- 360° beam angle for broad, all-around illumination
- Available in 3000K, 4500K & 6000K
- CRI >80
- Wide-range 100–240V AC operation
- Power factor >0.90
- Non-dimmable
- Durable aluminum and PVC construction
- Rated life exceeding 50,000 hours
- Operating temperature from -4°F to 122°F (-20°C to 50°C)
- CE, RoHS & FCC compliant
- 2-year warranty
Available Models
| Model No. | Color Temperature | Description | Lumens |
| CL-E40-20W-30K | 3000K | Warm White | 1,400 lm |
| CL-E40-20W-45K | 4500K | Natural White | 1,400 lm |
| CL-E40-20W-60K | 6000K | Bright White | 1,500 lm |
Color Temperature Options
| Color Temperature | Description | Lumens |
| 3000K | Warm White | 1,400 lm |
| 4500K | Natural White | 1,400 lm |
| 6000K | Bright White | 1,500 lm |
Specifications
| Product Type | LED Corn Lamp |
| Series | Clima 20 Corn Lamp Series |
| Power | 20W |
| Equivalent Wattage | Up to 100W |
| Light Output | 1,400–1,500 lm |
| Input Voltage | 100–240V AC |
| Base | E40 Mogul Base |
| LED Quantity | 48 High Power LEDs |
| LED Source | Epistar |
| Color Temperatures | 3000K / 4500K / 6000K |
| CRI | >80 |
| Beam Angle | 360° |
| Power Factor | >0.90 |
| Dimming | Non-Dimmable |
| Body Material | Aluminum + PVC |
| Diameter | 3.19" (81 mm) |
| Height | 9.17" (233 mm) |
| Operating Temperature | -4°F to 122°F (-20°C to 50°C) |
| Rated Life | >50,000 Hours |
| Compliance | CE / RoHS / FCC |
| Warranty | 2 Years |
Applications
- Commercial Lighting
- Residential Lighting
- General Illumination
- Compatible E40 Mogul Base Fixtures
- Ceiling Fixtures
- Post Lights
- Area Lighting Fixtures
- Replacement Lamp Applications
Why Choose the E40 Clima Corn Lamp?
The 20W Clima Corn Lamp with E40 Mogul Base provides up to 1,500 lumens while consuming only 20W. Its 360° beam angle distributes light in all directions, making it an efficient replacement solution for compatible fixtures requiring broad illumination.
With Epistar LED technology, three color temperature options, wide-range 100–240V AC compatibility, CRI greater than 80, durable aluminum and PVC construction, and a rated life exceeding 50,000 hours, the Clima 20 provides reliable performance for residential and commercial lighting applications.
