350W Constant Voltage Driver - 12V
350W Constant Voltage Driver - 12V
Couldn't load pickup availability
The 12V Constant Voltage 350W Multi-Purpose MeanWell LED Driver is a high-capacity constant voltage power supply designed for professional low-voltage LED lighting applications. Delivering DC 12V output at 29A, the driver supports loads up to 350W for high-power LED strips, RGB/DMX controllers, and other compatible 12V lighting systems.
Designed for larger installations, the driver features dual low-voltage DC connection slots, selectable AC input ranges, an integrated silent cooling fan, and multiple built-in protection features. Its rugged perforated metal housing promotes effective heat dissipation for reliable indoor operation.
Features
- 350W maximum output
- DC 12V, 29A output
- Constant voltage power supply design
- Dual low-voltage DC connection slots
- Allows connection of multiple compatible devices
- Selectable AC 100–120V / 200–240V input ranges
- Designed for high-power 12V LED lighting applications
- Compatible with LED strips and other low-voltage LED lighting
- Suitable for RGB and DMX controllers
- Standard 3-wire AC input connection slot
- Integrated silent cooling fan
- Built-in short-circuit protection
- Built-in overload protection
- Soft-start protection
- Integrated LED power indicator
- Rugged perforated metal housing for heat dissipation
- Non-dimmable
- IP20 rated for indoor use
- UL, CE, FCC, and RoHS certified
Input & Output Specifications
| Input Range | Input Current | Output | Maximum Load |
|---|---|---|---|
| AC 100–120V | 7.0A | DC 12V, 29A | 350W |
| AC 200–240V | 4.0A | DC 12V, 29A | 350W |
Specifications
| Product Type | Constant Voltage LED Driver |
|---|---|
| Model Number | NES-350-12 |
| Maximum Load | 350W |
| Input Voltage | AC 100–120V / 200–240V, 50/60Hz |
| Input Current | 7.0A @ 100–120V / 4.0A @ 200–240V |
| Input Selection | Selectable |
| Output Voltage | DC 12V |
| Output Current | 29A |
| Output Type | Constant Voltage |
| DC Connections | 2 Low-Voltage Connection Slots |
| AC Connection | 3-Wire Input Connection Slot |
| Dimming | Non-Dimmable |
| Cooling | Integrated Silent Cooling Fan |
| Protection | Short-Circuit / Overload / Soft Start |
| Protection Rating | IP20 |
| Housing | Perforated Metal |
| Dimensions | 8.98" × 4.49" × 1.97" (228 × 114 × 50 mm) |
| Weight | 2.0 lbs (907 g) |
| Shipping Weight | 3.5 lbs |
| Certifications | UL / CE / FCC / RoHS |
| Environment | Indoor / Dry Locations Only |
Applications
- High-Power 12V LED Strip Lighting
- RGB LED Lighting Systems
- RGB Controllers
- DMX Control Systems
- Low-Voltage LED Lighting
- Architectural Accent Lighting
- Display and Showcase Lighting
- Commercial Indoor Lighting Applications
- Multi-Device LED Lighting Installations
Why Choose the 12V Constant Voltage 350W Multi-Purpose MeanWell LED Driver?
With up to 350W of DC 12V power at 29A, this MeanWell LED driver is designed for larger LED installations requiring substantial and consistent low-voltage power. Dual DC connection slots provide additional flexibility when connecting multiple compatible lighting devices or controllers.
Its selectable input voltage, integrated cooling fan, short-circuit and overload protection, soft-start operation, LED power indicator, and rugged perforated metal housing make it a practical power solution for professional indoor 12V LED lighting systems.
